MTX-39
Fine Pitch Probe
Produkt Familie: METRIX
Kategorie: ICT / FCT
Electrical
| Current Rating (Amps) | 3 |
| Average DC Resistance lower than (mOhm) | 15 |
Mechanical
| Test Center (mil) | 39 |
| Test Center (mm) | 1.00 |
| Full Travel (mil) | 250 |
| Full Travel (mm) | 6.35 |
| Recommended Travel (mil) | 167 |
| Recommended Travel (mm) | 4.24 |
| Overall Length (mil) | 1,490 |
| Overall Length (mm) | 37.80 |
