MXLT-50
Fine Pitch Long Travel Probe
Produkt Familie: METRIX
Kategorie: ICT / FCT
Electrical
| Current Rating (Amps) | 6 |
| Average DC Resistance lower than (mOhm) | 10 |
Mechanical
| Test Center (mil) | 50 |
| Test Center (mm) | 1.27 |
| Full Travel (mil) | 400 |
| Full Travel (mm) | 10.16 |
| Full Travel Remark | Standard Spring: 400 mil / 10,16 mm, Alternate Spring 350 mil / 8,89 mm, High Spring: 350 mil / 8,89 mm |
| Recommended Travel (mil) | 315 |
| Recommended Travel (mm) | 8.00 |
| Overall Length (mil) | 1,640 |
| Overall Length (mm) | 41.70 |
