SPL-03C-090

Produkt Familie: SPL

Kategorie: Step Probe

Electrical

Current Rating (Amps)	6
Average Probe Resistance (mOhm)	50

Mechanical

Test Center (mil)	125
Test Center (mm)	3.18
Full Travel (mil)	250
Full Travel (mm)	6.35
Recommended Travel (mil)	127
Recommended Travel (mm)	3.22
Overall Length (mil)	1,530
Overall Length (mm)	38.86
Rec. Mounting Hole Size (mil)	95
Rec. Mounting Hole Size (mm)	2.40
Rec. Mounting Hole Remark	94 to 96 mil / 2.39 to 2.44 mm
Recommended Wire Gauge	22-26 AWG
Recommended Drill Size	#41 or 2.40 mm
